JINPAT Slip Rings Infuse Stable Rotational Power into Radar Antennas

In modern radar systems, antennas require360-degree continuous rotation for omnidirectional scanning. Providing stableand reliable transmission of power and control signals to the rotatingcomponents presents a key technical challenge. The JINPAT LPT038-0610-1205 throughbore slip ring is a precision solution specifically designed for such high-endapplications.

The LPT038‑0610‑1205 features athrough-bore structure with a 38 mm diameter central hole, facilitatingunobstructed passage for power cables and signal lines through the radarantenna's rotating platform. This slip ring is configured with 6 circuits ratedat 10 A and 12 circuits rated at 5 A, capable of handling the simultaneoustransmission needs for high-power supply and multiple low-current signals—suchas CAN bus, Ethernet, and control signals—within radar systems.

Leveraging its unique high-currenttransmission capability and compact design, it ensures that radar antennasmaintain ample power supply and precise signal control during high-speed,continuous rotation. It serves as a core component enhancing the overallperformance and reliability of radar systems.

Through JINPAT's advanced gold-gold contacttechnology, precision machining, and optimized thermal design, all circuitsmaintain extremely low contact resistance and electrical noise even underlong-term, high-speed operation, offering exceptional stability and an extendedservice life.

Choosing the JINPAT LPT038-0610-1205 slipring effectively resolves cable winding issues at rotational interfaces,enables 360-degree continuous device rotation, thereby significantly boostingoperational efficiency and intelligent functionality, and delivers long-term,reliable value returns for customers.
