JINPAT LPT000-1440-4S-04FO Marine Cable Reel Opto-Electrical Hybrid Slip Ring

In the turbulent and demanding environmentof marine operations, equipment reliability and durability are crucialdeterminants of operational efficiency and safety. As the core power supply andsignal transmission hub for equipment such as ships, port cranes, and offshoreplatforms, the performance of the slip ring within the cable reel is paramount.

The LPT000-1440-4S-04FO marine cable reelslip ring, specifically engineered by JINPAT for such harsh scenarios, combineshigh current, high voltage, multiple signals, and fiber optic transmission intoa single unit. Leveraging patented technology and exceptional design, itprovides a stable and reliable connection solution for modern marineengineering.

The LPT000-1440-4S-04FO slip ring excels inelectrical performance, capable of simultaneously meeting the dual demands ofhigh power and precise signals. In terms of power transmission, it cancurrently carry a robust current of up to 80A and possesses a maximum workingvoltage of 6.6KV and an exceptionally high withstand voltage strength of 10KV,ensuring stable operation in high-voltage environments without the risk ofelectrical breakdown. On the signal transmission front, it is perfectlycompatible with various control, data, and bus signals, enabling seamlessintegration. Particularly notable is its capacity to integrate up to 18 channelsof fiber optic slip rings, providing a future-proof solution for the growingneed for high-capacity, high-speed data transmission, such as videosurveillance and radar data, truly achieving efficient hybrid"electrical" and "optical" transmission.

To withstand the high corrosion, high saltspray, and pervasive dust and moisture typical of marine environments, thisslip ring features a comprehensive reinforcement design in its structure andmaterials. It utilizes a corrosion-resistant stainless steel housing,significantly enhancing the product's service life in harsh marine atmosphericconditions. Simultaneously, the overall protection rating reaches IP56,effectively preventing dust ingress and protecting against powerful jets andwaves of water, ensuring the internal precision components remain intact overthe long term. This compact design, which integrates high-voltage tolerance,fiber optic integration, and robust environmental protection, not onlyaddresses the space constraints common on marine equipment but also, with itsultra-high reliability and durability, makes it an ideal choice for cable reelsystems in critical applications such as ships, port cranes, and offshoreplatforms. Its innovative internal structure has already received the utilitymodel patent certification for "A High-Voltage Resistant, Compact MarineOpto-Electrical Hybrid Slip Ring."

Welcome to contact JINPAT for yourcustomized slip ring solutions.
