LPA000-03300-01PE-0350-0210-16S Large Volume Series Slip ring

share
copy Link
Facebook
Twitter
LinkedIn
Number of Circuits 25CKT
Insulation Resistance ≥1000MΩ@1000VDC(P) ≥500MΩ500VDC(S)
Contact Material High-end Copper Graphite/ Precious Metal
Consult immediately
Model ListInstallationReview(0)

This is a marine crane slip ring. Power capacity and channel number are optional.

Can integrate with signal module, pneumatic/hydraulic module and multi-channel fiber optic rotary joints.

Optional protection grading and explosion-proof grading.






Electronic & ElectrucMechanical
CircuitsTotal25CKTWorking Speed0~10RPM
Detail

3*300A+1*PE+3*50A+

2*10A+16*signal

A hole diameter/
Rating Voltage690VAC/380VAC/220VACContact Material

High-end Copper Graphite/

Precious Metal

Dielectric Strength

2000VAC@50Hz(P)
500VAC@50Hz(S)

HousingQ235 Spray Coating(RAL 7035)
Insulation Resistance

≥1000MΩ@1000VDC(P)

≥500MΩ500VDC(S)

installation

Vertical Installation
EnvironmentRemarks
Working Temperature-10°C~+45°CApplicationMarine Crane
Working Humidity≥95%RH
IPIP44Other/




For more details of this slip ring product, please contact JINPAT.

We will bring you a satisfactory custom solution!
