Features:

• High-Speed Ethernet: Supports 100M/1G/10G Ethernet with stable data transmission, zero packet loss, and minimal signal degradation.
• Power & Data Combination: Includes power transfer with Ethernet data.
• Durable & Reliable: Built to withstand harsh environments and ensure stable performance.
• Compact Design: Space-saving and easy to integrate into various systems.
• Customizable Options: Tailored to meet specific needs, including Ethernet quantity, other signal types, current, voltage and connector types.

Consult immediately

Model ListInstallationReview(0)

Ethernet Slip Rings

Ethernet slip rings are electromechanical components designed to transmit Ethernet signals, power, and multiple data types seamlessly during 360° continuous rotation of equipment. Featuring a robust design with a rotating part (rotor) and a stationary part (stator), they ensure uninterrupted signal transfer through precision contact technology. These slip rings support 100Mbps,1Gbps, and 10Gbps Ethernet protocols, making them ideal for high-demand applications such as HD video surveillance, industrial automation, and aerospace systems. Available in multiple configurations — including through-bore slip rings (hollow-shaft), capsule slip rings (compact), separate slip rings (modular), and pancake slip rings (flat-profile) — all supporting integrated Ethernet channels, they adapt to diverse spatial and functional requirements.

Applications:

Robotics
Rotating Machinery
CCTV & Surveillance
Aerospace & Aviation
Medical Equipment
Automated Testing Systems

Customization & Services
Tailor your slip ring with specific signal types, channel counts, protection levels, or mounting styles. 3D CAD models and technical support are available upon request.

Can’t find a suitable model? Contact us for 24/7 technical support .

For detailed product specifications , refer to product datasheets or contact our sales team.

Optimized for global markets – Precision-engineered for reliability in mission-critical applications.

Ethernet Slip Rings(Through-bore Type)
Type	Model	ID (mm)	OD (mm)	Etherne‍‍t(Max. 8 channels)		Current Circuits			IP
				Ethernet Support	Ethernet Channels(set)	5A/Signal	10A	15A
				Ethernet Support	Ethernet Channels(set)	5A/Signal	10A	15A
LPT025	LPT025-0605-01E(2-3)	∅25.4	∅86	100M ✔ / 1G ✔	1	6			IP50~IP68
	LPT025-0610-01E(2-3)						6
	LPT025-0615-01E(2-3)							6
	LPT025-1205-01E(2-3)					12
	LPT025-1210-01E(2-3)						12
	LPT025-1215-01E(2-3)							12
	LPT025-0605-02E(2-3)			100M ✔ / 1G ✔	2	6
	LPT025-0610-02E(2-3)						6
	LPT025-0615-02E(2-3)							6
	LPT025-1205-02E(2-3)					12
	LPT025-1210-02E(2-3)						12
	LPT025-1215-02E(2-3)							12
LPT038	LPT038-0605-01E(2-3)	∅38.1	∅99	100M ✔ / 1G ✔	1	6			IP50~IP68
	LPT038-0610-01E(2-3)						6
	LPT038-0615-01E(2-3)							6
	LPT038-1205-01E(2-3)					12
	LPT038-1210-01E(2-3)						12
	LPT038-1215-01E(2-3)							12
	LPT038-0605-02E(2-3)			100M ✔ / 1G ✔	2	6
	LPT038-0610-02E(2-3)						6
	LPT038-0615-02E(2-3)							6
	LPT038-1205-02E(2-3)					12
	LPT038-1210-02E(2-3)						12
	LPT038-1215-02E(2-3)							12
LPT050	LPT050-0605-01E(2-3)	∅50	∅119	100M ✔ / 1G ✔	1	6			IP50~IP68
	LPT050-0610-01E(2-3)						6
	LPT050-0615-01E(2-3)							6
	LPT050-1205-01E(2-3)					12
	LPT050-1210-01E(2-3)						12
	LPT050-1215-01E(2-3)							12
	LPT050-0605-02E(2-3)			100M ✔ / 1G ✔	2	6
	LPT050-0610-02E(2-3)						6
	LPT050-0615-02E(2-3)							6
	LPT050-1205-02E(2-3)					12
	LPT050-1210-02E(2-3)						12
	LPT050-1215-02E(2-3)							12
LPT060	LPT060-0605-01E(2-3)	∅60	∅135	100M ✔ / 1G ✔	1	6			IP50~IP68
	LPT060-0610-01E(2-3)						6
	LPT060-0615-01E(2-3)							6
	LPT060-1205-01E(2-3)					12
	LPT060-1210-01E(2-3)						12
	LPT060-1215-01E(2-3)							12
	LPT060-0605-02E(2-3)			100M ✔ / 1G ✔	2	6
	LPT060-0610-02E(2-3)						6
	LPT060-0615-02E(2-3)							6
	LPT060-1205-02E(2-3)					12
	LPT060-1210-02E(2-3)						12
	LPT060-1215-02E(2-3)							12
LPT070	LPT070-0605-01E(2-3)	∅70	∅135	100M ✔ / 1G ✔	1	6			IP50~IP68
	LPT070-0610-01E(2-3)						6
	LPT070-0615-01E(2-3)							6
	LPT070-1205-01E(2-3)					12
	LPT070-1210-01E(2-3)						12
	LPT070-1215-01E(2-3)							12
	LPT070-0605-02E(2-3)			100M ✔ / 1G ✔	2	6
	LPT070-0610-02E(2-3)						6
	LPT070-0615-02E(2-3)							6
	LPT070-1205-02E(2-3)					12
	LPT070-1210-02E(2-3)						12
	LPT070-1215-02E(2-3)							12
LPT080	LPT080-0605-01E(2-3)	∅80	∅160	100M ✔ / 1G ✔	1	6			IP50~IP68
	LPT080-0610-01E(2-3)						6
	LPT080-0615-01E(2-3)							6
	LPT080-1205-01E(2-3)					12
	LPT080-1210-01E(2-3)						12
	LPT080-1215-01E(2-3)							12
	LPT080-0605-02E(2-3)			100M ✔ / 1G ✔	2	6
	LPT080-0610-02E(2-3)						6
	LPT080-0615-02E(2-3)							6
	LPT080-1205-02E(2-3)					12
	LPT080-1210-02E(2-3)						12
	LPT080-1215-02E(2-3)							12
LPT096	LPT096-0605-01E(2-3)	∅96	∅185	100M ✔ / 1G ✔	1	6			IP50~IP68
	LPT096-0610-01E(2-3)						6
	LPT096-0615-01E(2-3)							6
	LPT096-1205-01E(2-3)					12
	LPT096-1210-01E(2-3)						12
	LPT096-1215-01E(2-3)							12
	LPT096-0605-02E(2-3)			100M ✔ / 1G ✔	2	6
	LPT096-0610-02E(2-3)						6
	LPT096-0615-02E(2-2)							6
	LPT096-1205-02E(2-3)					12
	LPT096-1210-02E(2-3)						12
	LPT096-1215-02E(2-3)							12
Model numbers decode key specs: For example, "LPT096-1215-02E(2-3)" breaks down as LPT (Through-bore type), 096mm inner diameter, 12 circuits at 15A, and 2 Ethernet channels (E4=10G; E2=100M, E3=1G).

Ethernet Slip Rings(Capsule Type)
Type	Model	OD (mm)	Ethernet		Current		IP
Type	Model	OD (mm)	Ethernet Support	Ethernet Channels (set)	Current Rating(A)	Current Circuits	IP
LPC-06	LPC-06-01E2	Φ22	100Mbps ✔	1	/	/	IP40~IP68
LPC-12	LPC-12-0602-01E2	Φ22	100Mbps ✔	1	2A	6	IP40~IP68
	LPC-12-0205-01E2		100Mbps ✔	1	5A	2
	LPC-12-01E3		1Gbps ✔	1	/	/
LPC-18	LPC-18-0602-02E2	Φ22	100Mbps ✔	2	2A	6	IP40~IP68
	LPC-18-0602-01E3		1Gbps ✔	1	2A	6
	LPC-18-0305-02E2		100Mbps ✔	2	5A	3
	LPC-18-0305-01E3		1Gbps ✔	1	5A	3
	LPC-18-0210-01E2		100Mbps ✔	1	10A	2
	LPC-18-0210-01E3		1Gbps ✔	1	10A	2
	LPC-18-01E4		2.5G✔ / 5G✔ / 10Gbps ✔	1	/	/
LPC-24	LPC-24-1202-02E2	Φ22	100Mbps ✔	2	2A	12	IP40~IP68
	LPC-24-1202-01E3		1Gbps ✔	1	2A	12
	LPC-24-0405-02E2		100Mbps ✔	2	5A	4
	LPC-24-0405-01E3		1Gbps ✔	1	5A	4
	LPC-24-0310-02E2		100Mbps ✔	2	10A	3
	LPC-24-0310-01E3		1Gbps ✔	1	10A	3
	LPC-24-0602-01E4		2.5G✔ / 5G✔ / 10Gbps ✔	1	2A	6
LPC-30	LPC-30-2002-02E2	Φ22	100Mbps ✔	2	2A	20	IP40~IP68
	LPC-30-2002-01E3		1Gbps ✔	1	2A	20
	LPC-30-0605-02E2		100Mbps ✔	2	5A	6
	LPC-30-0605-01E3		1Gbps ✔	1	5A	6
	LPC-30-0410-02E2		100Mbps ✔	2	10A	4
	LPC-30-0410-01E3		1Gbps ✔	1	10A	4
	LPC-30-1202-01E4		2.5G✔ / 5G✔ / 10Gbps ✔	1	2A	12
	LPC-30-0405-01E4		2.5G✔ / 5G✔ / 10Gbps ✔	1	5A	4
	LPC-30-0210-01E4		2.5G✔ / 5G✔ / 10Gbps ✔	1	10A	2
LPC-36	LPC-36-2402-02E2	Φ22	100Mbps ✔	2	2A	24	IP40~IP68
	LPC-36-2402-01E3		1Gbps ✔	1	2A	24
	LPC-36-0605-03E2		100Mbps ✔	3	5A	6
	LPC-36-0605-02E3		1Gbps ✔	2	5A	6
	LPC-36-0510-02E2		100Mbps ✔	2	10A	5
	LPC-36-0510-01E3		1Gbps ✔	1	10A	5
	LPC-36-02E4		2.5G✔ / 5G✔ / 10Gbps ✔	2	/	/
LPC-56	LPC-56-3002-04E2	Φ25	100Mbps ✔	4	2A	30	IP40~IP68
	LPC-56-3002-02E3		1Gbps ✔	2	2A	30
	LPC-56-1205-04E2		100Mbps ✔	4	5A	12
	LPC-56-1205-02E3		1Gbps ✔	2	5A	12
	LPC-56-0610-04E2		100Mbps ✔	4	10A	6
	LPC-56-0610-02E3		1Gbps ✔	2	10A	6
	LPC-56-06E3		2.5G✔ / 5G✔ / 10Gbps ✔	6	/	/
LPC-76	LPC-76-3002-06E2	Φ35.5	100Mbps ✔	6	2A	30	IP40~IP68
	LPC-76-3002-04E3		1Gbps ✔	4	2A	30
	LPC-76-1205-06E2		100Mbps ✔	6	5A	12
	LPC-76-1205-04E3		1Gbps ✔	4	5A	12
	LPC-76-0610-02E2		100Mbps ✔	2	10A	6
	LPC-76-0610-01E3		1Gbps ✔	1	10A	6
	LPC-76-0615-04E2		100Mbps ✔	4	15A	6
	LPC-76-0615-02E3		1Gbps ✔	2	15A	6
	LPC-76-0620-02E2		100Mbps ✔	2	20A	6
	LPC-76-0620-01E3		1Gbps ✔	1	20A	6
LPM-06	LPM-06-01E2	Φ12.5	100Mbps ✔	1	/	/	IP40~IP68
LPM-12	LPM-12-0402-01E2	Φ12.5	100Mbps ✔	1	2A	4	IP40~IP68
	LPM-12-0105-01E2		100Mbps ✔	1	5A	1
	LPM-12-01E3		1Gbps ✔	1	/	/
LPM-18	LPM-18-1201-01E2	Φ12.5	100Mbps ✔	1	1A	12	IP40~IP68
	LPM-18-0601-02E2		100Mbps ✔	2	1A	6
	LPM-18-0601-01E3		1Gbps ✔	1	1A	6
	LPM-18-0205-02E2		100Mbps ✔	2	5A	2
	LPM-18-0205-01E3		1Gbps ✔	1	5A	2
LPM-24	LPM-24-0601-03E2	Φ15.5	100Mbps ✔	3	1A	6	IP40~IP68
	LPM-24-0601-02E3		1Gbps ✔	2	1A	6
	LPM-24-1201-02E2		100Mbps ✔	2	1A	12
	LPM-24-1201-01E3		1Gbps ✔	1	1A	12
	LPM-24-0305-01E2		100Mbps ✔	1	5A	3
	LPM-24-0305-01E3		1Gbps ✔	1	5A	3
LPM-30	LPM-30-0601-04E2	Φ16	100Mbps ✔	4	1A	6	IP40~IP68
	LPM-30-0601-04E3		1Gbps ✔	4	1A	6
	LPM-30-1201-03E2		100Mbps ✔	3	1A	12
	LPM-30-1201-02E3		1Gbps ✔	2	1A	12
	LPM-30-0405-02E2		100Mbps ✔	2	5A	4
	LPM-30-0405-01E3		1Gbps ✔	1	5A	4
LPMS-06	LPM-06-01E2	Φ7.9	100Mbps ✔	1	/	/	Customizable
LPMS-08	LPM-08-0301-01E2	Φ5.5	100Mbps ✔	1	1A	3	Customizable
LPMS-12	LPMS-12-0701-01E2	Φ6.5	100Mbps ✔	1	1A	7	Customizable
LPMS-12	LPMS-12-0201-02E2	Φ6.5	100Mbps ✔	2	1A	2	Customizable
LPMS-15	LPMS-15-1001-01E2	Φ7.6	100Mbps ✔	1	1A	10	Customizable
	LPMS-15-0501-02E2		100Mbps ✔	2	1A	5
	LPMS-15-0601-01E3		1Gbps ✔	1	1A	6
LPMS-18	LPMS-18-0601-02E2	Φ7.98	100Mbps ✔	2	1A	6	Customizable
	LPMS-18-1201-01E2		100Mbps ✔	1	1A	12
	LPMS-18-0901-01E3		1Gbps ✔	1	1A	9
	LPT-18-02E3		1Gbps ✔	2	/	/
Model Decoding: Example: "LPC-30-0210-01E4" = LPC (Capsule type), 30 total channels, 2×10A power circuits, and 1×10G Ethernet (E4=10G; E2=100M, E3=1G).
