High Current Integrated Slip Rings

JINPAT High Current Integrated Slip Rings are engineered to provide stable and reliable transmission of large current, power, and signals during continuous rotation. The integrated design allows high-power current channels and signal circuits to be combined within a compact structure, making the product suitable for complex industrial systems that require both power and data transmission.

Manufactured with high-grade materials and durable carbon brush technology, each ring can support current capacity of up to 4000A, ensuring stable power transmission with low contact resistance, smooth rotation, and reduced friction. The robust design provides excellent electrical performance and long service life even in demanding operating environments.

These slip rings support customizable current capacity, circuit configuration, rotational speed, operating temperature, and protection levels, allowing them to meet diverse industrial requirements. They are widely used in industries such as offshore oil and gas, oceanographic exploration, seismic equipment, marine engineering, and heavy industrial machinery.

With over 30 years of experience in slip ring design and manufacturing, JINPAT delivers high-performance and reliable high current slip ring solutions tailored to global industrial applications.

Typical applications:   Oil drilling platform, harbor machinery, ship and crane, etc.

LPA Series Specifications

Series No.

Max IP Grade

Explosion-proof

Outlet Way

Rotor/Stator Installation Method

Round Series 1

IP68

YES

with/without wire

design by customer's request

Round Series 2

IP68

YES

with wire

/

Round Series 3

IP54/IP51

NO

with/without wire

/

Square Series 1

IP68

YES

with/without wire

/

Square Series 2

IP54

NO

with/without wire

/

Square Series 3

IP68

NO

with wire

/

LPA Round Series

Dimension

Circuits

Rating Current(optional)

Max Rated Voltage

Round Series(optional)

D1

D2

L1

L2

Optional

60A

100A

130A

/

690V

Series 1

Series 2

Series 3

300

300

according to circuits and other specifications

Optional

√

√

√

350

350

Optional

95A

150A

260A

/

√

√

√

450

450

Optional

150A

250A

340A

/

√

√

√

500

500

Optional

220A

370A

500A

/

√

√

√

560

560

Optional

220A

370A

500A

/

√

√

√

720

720

Optional

300A

500A

680A

850A

√

√

√

Round Series1

Round Series2

Round Series3

LPA Square Series

Dimension

Circuits

Rating Current(optional)

Max Rated Voltage

Square Series(optional)

W2

L2

L1/D1

W1

H1

H2

Optional

60A

100A

130A

/

690V

Series 1

Series 2

Series 3

300

300

according to circuits and other specifications

Optional

√

√

√

350

350

Optional

95A

150A

260A

/

√

√

√

450

450

Optional

150A

250A

340A

/

√

√

√

500

500

Optional

220A

370A

500A

/

√

√

√

560

560

Optional

220A

370A

500A

/

√

√

√

720

720

Optional

300A

500A

680A

850A

√

√

√

Square Series1

Square Series2

Square Series3
