This series is divided into an integrated pancake slip ring and a separate pancake slip ringThe integrated pancake slip rings provide vias of different size; the separate pancake slip ring consists of a separate rotor and a stator to meet more stringent height requirements, and can be installed by the customer according to the application environment.
Features:
Minimum thickness up to 5.4m
Transmit analog and digital signal
The power and signal are mixed transmitted, and the signal categories are as follows:
◎Ethernet: Rate (10Mbps/100Mbps/1000Mbps)
◎Industrial Ethernet: ProfiNet, Powerlink, SercosIII, EtherCAT, EtherNet/IP, etc.
◎HD video: SDI, LVDS, etc.
◎Serial communication: RS232, RS485, RS422, etc.
◎Universal Serial Bus: USB2.0
◎Industrial Fieldbus: CANBus, CC-Link, InterBus, DeviceNet, ProfiBus, etc.
◎Sensor signal: thermal resistance, thermocouple, strain gauge, etc.
◎Shock-resistant, maintenance-free
Main Applications:
◎ Military Equipments
◎ Medical Equipments
◎ Wind Turbine
◎ Test Equipment
◎ Revolving Door
◎ Robot
| LPKS Pancake Slip Rings | ||||||||
| Model | Number of Circuits | Voltage （AC/DC） | Current (A) | OD*Length (L）/（mm） | (ID)（mm） | Reference Circle (D)/（mm） | Details | Downloads |
| LPKS005-0105 | 1 | 240V | 5 | Ф34×7 | 5 | 30 |  | / |
| LPKS005-0205 | 2 | 240V | 5 | Ф42×7 | 5 | 38 | | / |
| LPKS005-0305 | 3 | 240V | 5 | Ф52×7 | 5 | 46 | | / |
| LPKS005-0405 | 4 | 240V | 5 | Ф60×7 | 5 | 54 | | / |
| LPKS005-0505 | 5 | 240V | 5 | Ф68×7 | 5 | 63 | | / |
| LPKS005-0605 | 6 | 240V | 5 | Ф76×7 | 5 | 70 | | / |
| LPKS005-0705 | 7 | 240V | 5 | Ф84×7 | 5 | 78 | | / |
| LPKS005-0805 | 8 | 240V | 5 | Ф92×7 | 5 | 86 | | / |
| LPKS005-0905 | 9 | 240V | 5 | Ф100×7 | 5 | 94 | | / |
| LPKS005-1005 | 10 | 240V | 5 | Ф108×7 | 5 | 102 | | / |
| LPKS019-0905 | 9 | 240V | 5 | Ф108×7 | 19 | 102 | | / |
| LPKS028-0805 | 8 | 240V | 5 | Ф108×7 | 28 | 102 | | / |
| LPKS036-0705 | 7 | 240V | 5 | Ф108×7 | 36 | 102 | | / |
| LPKS045-0605 | 6 | 240V | 5 | Ф108×7 | 45 | 102 | | / |
| LPKS053-0505 | 5 | 240V | 5 | Ф108×7 | 53 | 102 | | / |
| LPKS061-0405 | 4 | 240V | 5 | Ф108×7 | 61 | 102 | | / |
| LPKS069-0305 | 3 | 240V | 5 | Ф108×7 | 69 | 102 | | / |
| LPKS076-0205 | 2 | 240V | 5 | Ф108×7 | 76 | 102 | | / |
| LPKS084-0105 | 1 | 240V | 5 | Ф108×7 | 84 | 102 | | / |
Installation Instructions of Separate Pancake Slip Ring
1. First install the rotor side. Fix the rotor PCB board to the flange of the device with the corresponding screws;
2. Then install the stator side. Fix the stator PCB board to the flange of the device with the corresponding screws;
3. Debug the coaxiality of the slip ring. The brush shrapnel contacts on the stator side must be adjusted to the center of the rotor side ring to ensure the coaxiality between the slip ring and the device;
4. Debug the distance between the two PCB boards. The distance between the stator side PCB board and the rotor side PCB board is L (+0.1/+0.3) mm.
